Product Summary
The TLE2027ID contain innovative circuit design expertise and high-quality process control techniques to produce a level of ac performance and dc precision previously unavailable in single operational amplifiers. Manufactured using Texas Instruments state-of-the-art Excalibur process, these devices allow upgrades to systems that use lower-precision devices. In the area of dc precision, the TLE2027ID offer maximum offset voltages of 100 µV and 25 µV, respectively, common-mode rejection ratio of 131 dB (typ), supply voltage rejection ratio of 144 dB (typ), and dc gain of 45 V/μV (typ).
Parametrics
Absolute maximum ratings: (1)Supply voltage, VCC+ (see Note 1): 19 V; (2)Supply voltage, VCC–: -19 V; (3)Differential input voltage, VID (see Note 2): ±1.2 V; (4)Input voltage range, VI (any input): VCC±; (5)Input current, II (each Input): ±1 mA; (6)Output current, IO: ± 50 mA; (7)Total current into VCC+: 50 mA; (8)Total current out of VCC–: 50 mA; (9)Duration of short-circuit current at (or below) 25°C (see Note 3): unlimited; (10)Continuous total power dissipation: See Dissipation Rating Table; (11)Operating free-air temperature range, TA, C suffix: 0°C to 70°C; (12)Operating free-air temperature range, TA, I suffix: – 40°C to 105°C; (13)Operating free-air temperature range, TA, M suffix: – 55°C to 125°C; (14)Storage temperature range, Tstg: –65°C to 150°C; (15)Case temperature for 60 seconds, TC: FK package: 260°C; (16)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D or P packag. 260°C; (17)Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: JG package.300°C.
Features
Features: (1)Outstanding Combination of dc Precision and AC Performance; (2)Available in Standard-Pinout Small-Outline Package; (3)Output Features Saturation Recovery Circuitry; (4)Macromodels and Statistical information.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 TLE2027ID |
Texas Instruments |
Operational Amplifiers - Op Amps Low Noise High Gain |
Data Sheet |
|
|
||||||||||||
|
TLE2027IDG4 |
Texas Instruments |
Operational Amplifiers - Op Amps Low Noise High Gain |
Data Sheet |
|
|
||||||||||||
|
TLE2027IDRG4 |
Texas Instruments |
Operational Amplifiers - Op Amps Low-Noise Precision Op Amp |
Data Sheet |
|
|
||||||||||||
|
TLE2027IDR |
Texas Instruments |
Operational Amplifiers - Op Amps Low-Noise Precision Op Amp |
Data Sheet |
|
|
||||||||||||
